Plymouth Voyager III (1995-2000) stop lamp switch controller anti-lock brake Wiring diagram
This page shows the only wiring diagram for the component.stop lamp switch controller anti-lock brake, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp switch controller anti-lock brake (1 of 1)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
AUTOMATIC SHUT DOWN RELAY
BLK WIRE
BODY CONTROL MODULE
CANADA
CIGAR/ ACCES- SORY RELAY
COMBINATION FLASHER/DRL MODULE BODY CONTROL MODULE
COURTESY LAMP RELAY
DATA LINK CONNECTOR
DK BLU WIRE
DK GRN WIRE
FROM FUSE 21 (DIAGRAM 1 OF 3)
FRONT CIGAR LIGHTER
FRONT READING LAMPS/ SWITCH
FUEL PUMP MODULE
FUEL PUMP RELAY
FUSE 10
FUSE 11
FUSE 13 FUSE 12
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 28
FUSE 8
FUSE 9
GRY WIRE
HIGH BEAM RELAY
HORN RELAY
INSTRU- MENT CLUSTER
JUNCTION BLOCK
LEFT MID READING LAMP LEFT REAR READING LAMP
LEFT QUARTER PANEL)
LEFT VISOR/ VANITY MIRROR LAMPS
LOW BEAM RELAY
LOW NOTE HORN HIGH NOTE HORN
MEMORY SEAT/MIRROR MODULE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION CENTER
POWER MIRROR SWITCH GLOVE BOX LAMP
POWERTRAIN CONTROL MODULE
RADIO
REAR CIGAR LIGHTER/ POWER OUTLET
RED WIRE
REMOTE KEYLESS ENTRY MODULE MESSAGE CENTER
RIGHT MID READING LAMP
RIGHT REAR READING LAMP
RIGHT VISOR/VANITY MIRROR LAMPS
STOP LAMP SWITCH CONTROLLER ANTI-LOCK BRAKE
TO ENGINE CONTROLS SYSTEM
TO IGNITION SWITCH (PIN 1) (DIAGRAM 1 OF 3)
TRANSMISSION CONTROL MODULE
TRANSMISSION CONTROL RELAY
TRANSMISSION CONTROL SOLENOIDS
UNIVERSAL GARAGE DOOR OPENER
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> STOP LAMP SWITCH CONTROLLER ANTI-LOCK BRAKE
