Plymouth Voyager III (1995-2000) pnk data link connector pnk Wiring diagram
This page shows the only wiring diagram for the component.pnk data link connector pnk, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk data link connector pnk (1 of 1)
1 2 CCD BUS (+) CCD BUS (-) COMPUTER DATA LINES
ANTENNA
B(+)
BLK WIRE
BRN/LT BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
DK BLU/ORG WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE 28
FUSE 8
GROUND (CENTER OF DASH)
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN OR ACC
JUNCTION BLOCK (UNDER LEFT SIDE OF DASH) BODY CONTROL MODULE
L FRONT (-) R FRONT (-) DIMMER SENS PANEL LAMPS FUSED IGN FUSED B(+)
L REAR (+) R REAR (+) L FRONT (+) R FRONT (+) L REAR (-) R REAR (-)
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
NCA WIRE
ORG/ WIRE
PANEL LAMPS FEED
PNK DATA LINK CONNECTOR PNK WIRE
PNK WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWER MIRROR SWITCH
RADIO
RED WIRE
RED/WHT WIRE
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
STEP DIMMER SENSE
VIO WIRE
VIO/BRN WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Radio circuits, base radio -> PNK DATA LINK CONNECTOR PNK WIRE
