Plymouth Voyager III (1995-2000) high temp sensor Wiring diagram
This page shows the only wiring diagram for the component.high temp sensor, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high temp sensor (1 of 1)
4 2 3 1 BATERY RLY CONT IN FAN OUT GROUND
5 1 OFF LOW MED 2 3 HI
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C ZONE DOOR ACTUATOR
BLEND DOOR ACTUATOR
BLK WIRE
BLK/LT BLU WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BRN/PNK WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/BLK WIRE
DK BLU/GRY WIRE
DK BLU/ORG WIRE
DK BLU/PNK WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/YEL WIRE
EVAPORATOR TEMPERATURE SENSOR
FUSE 11
FUSE 12
FUSE 24
FUSE 6
FUSE 9
GRY WIRE
GRY/DK BLU WIRE
HIGH TEMP SENSOR
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
HOT IN RUN, ACCY
JUNCTION BLOCK
LT GRN WIRE
LT GRN/DK BLU WIRE
MESSAGE CENTER
MODE DOOR ACTUATOR
OFF REAR LOW 3 1 HI
ORG/ WIRE
PNK/DK BLU WIRE
POWER DISTRIBUTION CENTER
PTC 1
RADIATOR FAN NO. 1
RADIATOR FAN NO. 2
RADIATOR FAN RELAY (FRONT OF LEFT FRAME RAIL)
REAR A/C HEATER UNIT (RIGHT QUARTER PANEL)
REAR BLOWER 3 2 MOTOR
REAR BLOWER FRONT CONTROL SWITCH
REAR BLOWER REAR CONTROL SWITCH
REAR MODE DOOR MOTOR
RECIRCULATION DOOR ACTUATOR (RIGHT SIDE OF HVAC UNIT)
RED WIRE
RED/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Air conditioning circuits (2 of 2) -> HIGH TEMP SENSOR
