Plymouth Voyager III (1995-2000) ect sensor sig Wiring diagram
This page shows the only wiring diagram for the component.ect sensor sig, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ect sensor sig (1 of 1)
AUTOMATIC SHUT DOWN RELAY
BATTERY
BLK WIRE
BLK/ WHT WIRE
BLK/DK GRN WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
BLK/TAN WIRE
BODY CONTROL MODULE (ON JUNCTION BLOCK, BEHIND LEFT SIDE OF DASH)
BRN WIRE
BRN/DK BLU WIRE
BRN/PNK WIRE
CKP SENSOR SIG CMP SENSOR SIG
DK BLU WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/ORG WIRE
DK GRN/RED WIRE
DK GRN/WHT WIRE
DOWNSTREAM HEATED OXYGEN SENSOR (FRONT CENTER OF FLOOR PAN, IN EXHAUST PIPE)
ECT SENSOR SIG
EGR SOLENOID CTRL
ENGINE STARTER MOTOR RELAY
EVAP/ PURGE SOLENOID (ON RIGHT SIDE OF ENG COMPT)
EXHAUST GAS RECIRCULATION SOLENOID (ON RIGHT REAR OF ENG)
FIELD COIL
FUEL PUMP MODULE (ON SIDE OF FUEL TANK)
FUEL PUMP RELAY
FUSE 16
FUSE 17
GENERATOR
GROUND IGN COIL DRIVER
GRY WIRE
GRY/BLK WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LAMP DRIVER
LEFT KICK PANEL GROUND BLOCK (LEFT KICK PANEL)
LT BLU/BRN WIRE
MESSAGE CENTER
NCA WIRE
ORG/DK BLU WIRE
PNK/ BLK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENG COMPT)
POWERTRAIN CONTROL MODULE (LEFT FENDER SIDE SHIELD)
PTC 1 FUSE 6
REAR GROUND BLOCK (LEFT QUARTER PANEL)
RED/WHT WIRE
SERVICE ENGINE SOON LAMP
START/RUN
STOP LAMP SWITCH (CRUISE CONTROL SYSTEM)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TAN/YEL WIRE
TP SENSOR SIGNAL MAP SENSOR SIG
UPSTREAM HEATED OXYGEN SENSOR (ON EXHAUST MANIFOLD)
WHT/BLK WIRE
WHT/DK BLU WIRE
YEL GRY/ WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0ls (1 of 3) -> ECT SENSOR SIG
