Plymouth Voyager III (1995-2000) 41 80 62 56 spd ctrl sw sig spd ctrl vent stop lmp sw sens spd ctrl vacuum Wiring diagram
This page shows the only wiring diagram for the component.41 80 62 56 spd ctrl sw sig spd ctrl vent stop lmp sw sens spd ctrl vacuum, which is found in the car Plymouth Voyager III (1995-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 41 80 62 56 spd ctrl sw sig spd ctrl vent stop lmp sw sens spd ctrl vacuum (1 of 1)
3.0L
41 80 62 56 SPD CTRL SW SIG SPD CTRL VENT STOP LMP SW SENS SPD CTRL VACUUM
78 66 SPD CTRL VACUUM VSS SIG
BLK WIRE
BLK/LT GRN WIRE
CLOCK- SPRING
COAST
DK BLU/RED WIRE
DUMP
EXCEPT 3.0L
LEFT SPEED CONTROL SWITCH
LT GRN/RED WIRE
NCA WIRE
POWERTRAIN CONTROL MODULE (FRONT OF LEFT FRONT FENDER)
RED/LT GRN WIRE
RESUME/ ACCEL
RIGHT SPEED CONTROL SWITCH
SET-
SPD CTRL ON/OFF SW
STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT)
TAN/RED WIRE
TRANSMISSION CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
VACUUM
VEHICLE SPEED CONTROL SERVO (LEFT REAR OF ENGINE)
VEHICLE SPEED SENSOR (ON TRANSMISSION)
VENT
W/ATX
W/EATX
WHT WIRE
WHT/ORG WIRE
WHT/PNK WIRE
YEL/RED WIRE
Go to component -> Cruise control circuit -> 41 80 62 56 SPD CTRL SW SIG SPD CTRL VENT STOP LMP SW SENS SPD CTRL VACUUM
