Plymouth Voyager III (1995-2000) 38 7 rear wiper/washer mux wiper mux sig Wiring diagram

100 OHM 38 7 REAR WIPER/WASHER MUX WIPER MUX SIG 64.9 OHM 90.9 OHM A/C HEATER CONTROL MODULE (DASH CENTER STACK) BLK WIRE BLK/LT GRN WIRE BLK/TAN WIRE BLK/WHT WIRE BODY CONTROL MODULE BRN WIRE BRN/LT GRN WIRE BRN/PNK WIRE BRN/WHT WIRE DK BLU WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE ELECTRIC WIPER DE-ICE CRTL ELECTRIC WIPER DE-ICER (AT BASE OF WINDSHIELD) FRONT WASHER MOTOR (BOTTOM OF WASHER FLUID BOTTLE) FRONT WASHER MOTOR CTRL FRONT WIPER SWITCH (PART OF MULTI- FUNCTION SWITCH) FUSE 19 FUSE 6 FUSE 9 HI LO HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN RUN OR START HVAC CONTROL IGN RUN/START JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LOW WASHER FLUID LEVEL SWITCH (BOTTOM OF WASHER RESERVOIR) OFF POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) PTC 9 REAR WASHER MOTOR (BOTTOM OF WASHER FLUID BOTTLE) REAR WASHER SW REAR WASHER SW SENSE REAR WIPER DELAY ON IND REAR WIPER DELAY ON IND DRIVER REAR WIPER DELAY SW REAR WIPER DELAY SW SENSE REAR WIPER MOTOR (CENTER OF LIFTGATE) REAR WIPER ON IND REAR WIPER ON IND DRIVER REAR WIPER ON SW REAR WIPER/ WASH MUX RED WIRE RED/VIO WIRE RED/YEL WIRE WASH WHT WIRE WIPER HIGH/ LOW RELAY WIPER MODULE (LEFT REAR CORNER OF ENGINE COMPT) WIPER ON RELAY YEL/WHT WIRE
