Car Wiring Diagrams for Warning system circuits for Plymouth Breeze I (1995-2000)

1 11 17 CCD BUS (+) CCD BUS (-) KEY-IN IGNITION SWITCH SENSE BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BODY CONTROL MODULE CCD (+) CCD (-) DK BLU WIRE FUSE 11 FUSE 5 FUSE 7 FUSE 9 FUSED B (+) FUSED IGN GROUND HEAD OFF HEADLAMP SWITCH HOT AT ALL TIMES HOT IN OFF, RUN OR START IGN (ST-RUN) PARK LAMP SWITCH OUTPUT IGNITION SWITCH INSTRUMENT CLUSTER JUNCTION BLOCK (UNDER LEFT SIDE OF DASH) KEY-IN SWITCH (PART OF IGNITION SWITCH) LEFT FRONT DOOR AJAR SWITCH LEFT FRONT DOOR AJAR SWITCH SENSE LEFT REAR DOOR AJAR SWITCH LEFT REAR DOOR AJAR SWITCH SENSE LOCK OFF LT BLU WIRE LT GRN/RED WIRE PARK RIGHT FRONT DOOR AJAR SWITCH RIGHT FRONT DOOR AJAR SWITCH SENSE RIGHT REAR DOOR AJAR SWITCH SENSE RIGHT REAR DOOR AJAR SWITCH RUN WIRE SEAT BELT INDICATOR SEAT BELT SWITCH SEAT BELT SWITCH SENSE TAN WIRE TAN/ORG WIRE TAN/PNK WIRE TAN/RED WIRE VIO/BRN WIRE WHT/DK BLU WIRE
