Oldsmobile Silhouette II (1996-2004) Charging circuit

ALT/SENSE FUSE BATTERY BATTERY INDICATOR BLK WIRE CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA LINE COMPUTER DATA LINES DK GRN WIRE FUSIBLE LINK A (10 GA- RUST) GENERATOR B+ GENERATOR TERMINAL L OUTPUT GRY WIRE HOT AT ALL TIMES HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK (RIGHT SIDE OF DASH) IGN 1 FUSE INSTRUMENT PANEL CLUSTER (IPC) MICRO- PROCESSOR CLASS 2 (PCM) MICRO- PROCESSOR IGN 1 VOLTAGE ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE STARTER UNDERHOOD FUSE BLOCK (IN ENGINE COMPT, FRONT OF RIGHT WHEELHOUSE ABOVE BATTERY)
