Car Wiring Diagrams for Instrument illumination circuit for Oldsmobile Silhouette II (1996-2004)

AUXILIARY BLOWER SWITCH AUXILIARY REAR HVAC CONTROL MODULE LEFT FRONT DOOR LOCK SWITCH BLK WIRE BRN WIRE DC DIM FOGLAMP/ TCS SWITCH HEATED SEAT SWITCH FUSE BLOCK GRND GRY WIRE GRY/BLK WIRE HEADLAMP SWITCH HOT AT ALL TIMES HVAC CONTROL MODULE INCANDESCENT DIM INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT CLUSTER INTERIOR LAMP, MULTI- FUNCTION SWITCH ASSEMBLY INTERIOR LAMPS OVERRIDE SWITCH LEFT FRONT WINDOW SWITCH LEFT POWER SLIDING DOOR OPEN/CLOSE SWITCH LEFT STEERING WHEEL CONTROLS MEMORY SEAT SWITCH MULTIFUNCTION SWITCH ORG/ WIRE OVER- HEAD CONSOLE PWM DIM PARK LP FUSE POWER SLIDING DOOR SWITCH RIGHT POWER SLIDING DOOR OPEN/CLOSE SWITCH PWM DIM RADIO REAR POWER QUARTER WINDOW SWITCH REAR SEAT AUDIO (RSA) CONTROL REAR VIDEO/ AUDIO HVAC MODULE REAR WINDOW WIPER/ WASHER SWITCH RIGHT FRONT DOOR LOCK SWITCH RIGHT FRONT WINDOW SWITCH RIGHT STEERING WHEEL CONTROLS STEP DIM SWC BACK- LIGHT FUSE UNDERHOOD JUNCTION BLOCK VF DIM WHT WIRE
