Oldsmobile Silhouette II (1996-2004) cable motor ctrl cable motor ctrl Wiring diagrams
This page contains all the electrical diagrams for the component. cable motor ctrl cable motor ctrl, in which he is found in the car Oldsmobile Silhouette II (1996-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cable motor ctrl cable motor ctrl (1 of 2)
1 2 3 4 RETURN
389 1892 ENGINE CONTROLS SYSTEM
39 640 PNK WIRE
AJAR
ALARM
B/U LAMP FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH)
CABLE MOTOR
CABLE MOTOR CTRL CABLE MOTOR CTRL
CLUTCH
CLUTCH CTRL LO CLUTCH CTRL HI
CONTROL
DK GRN WIRE
GRY WIRE
HI CURRENT BATTERY PWR SLIDING DOOR REL GROUND
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (RIGHT SIDE OF DASH)
IGN 1 FUSE
INTERIOR LAMP, MULTI-FUNCTION SWITCH ASSEMBLY
LEFT POWER SLIDING DOOR UNLATCH ACTUATOR
LT BLU/BLK WIRE
LT GRN WIRE
NCA WIRE
OFF POWER SLIDING DOOR ON/OFF SWITCH
OPEN LATCHED
OPTICAL SENSOR
ORG/ WIRE
PARK
PARK/NEUTRAL POSITION SWITCH (MOUNTED ON TOP OF TRANSAXLE)
PNK WIRE
POWER SLIDING DOOR DETENT SWITCH
POWER SLIDING DOOR OPEN/ CLOSE SWITCH (MIDDLE OF LEFT "B" PILLAR)
POWER SLIDING DOOR OPEN/ CLOSE SWITCH (MOMENTARY)
PWR SLDG DR CIRCUIT BREAKER
RADIO FUSE
REAR DOOR ACTUATOR (LEFT QUARTER PANEL, ABOVE WHEELWELL)
SIGNAL SIGNAL
SLIP RING
SW CLSD W/DR HANDLE PULLED
TRANSAXLE PARK POSITION INPUT SIG
UNDERHOOD FUSE BLOCK (ON RIGHT FRONT OF ENGINE COMPT)
YEL WIRE
Go to component -> Left sliding door circuit -> CABLE MOTOR CTRL CABLE MOTOR CTRL
Wiring diagram cable motor ctrl cable motor ctrl (2 of 2)
1 2 3 4 RETURN
389 1892 1894 39 640 1896 275 ENGINE CONTROLS SYSTEM
AJAR
ALARM
B/U LAMP FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BELOW RIGHT SIDE OF DASH)
CABLE MOTOR
CABLE MOTOR CTRL CABLE MOTOR CTRL
CLUTCH
CLUTCH CTRL LO CLUTCH CTRL HI
CONTROL
DK GRN WIRE
GRY WIRE
HI CURRENT BATTERY PWR SLIDING DOOR REL GROUND
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK (RIGHT SIDE OF DASH)
IGN 1 FUSE
INTERIOR LAMP, MULTI-FUNCTION SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
OFF POWER SLIDING DOOR ON/OFF SWITCH
OPEN LATCHED
OPTICAL SENSOR
ORG/ WIRE
PARK
PARK/NEUTRAL POSITION SWITCH (MOUNTED ON TOP OF TRANSAXLE)
PNK WIRE
POWER SLIDING DOOR DETENT SWITCH
POWER SLIDING DOOR OPEN/ CLOSE SWITCH (MIDDLE OF RIGHT "B" PILLAR)
POWER SLIDING DOOR OPEN/ CLOSE SWITCH (MOMENTARY)
PWR SLDG DR CIRCUIT BREAKER
RADIO FUSE
REAR DOOR ACTUATOR (RIGHT QUARTER PANEL, ABOVE WHEELWELL)
RIGHT POWER SLIDING DOOR UNLATCH ACTUATOR
SIGNAL SIGNAL
SLIP RING
SW CLSD W/DR HANDLE PULLED
TRANSAXLE PARK POSITION INPUT SIG
UNDERHOOD FUSE BLOCK (ON RIGHT FRONT OF ENGINE COMPT)
YEL WIRE
Go to component -> Right sliding door circuit -> CABLE MOTOR CTRL CABLE MOTOR CTRL
