Oldsmobile Silhouette II (1996-2004) bypass cntrl wiring diagram

18 19 PNK WIRE AIR PUMP RELAY (RIGHT SIDE OF ENGINE COMPT) BLK WIRE BLK/ WHT WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BYPASS CNTRL CRANKSHAFT POSITION SENSOR B DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ELEK IGN FUSE TCC FUSE ENGINE COOLANT TEMPERATURE SENSOR (TOP LEFT REAR OF ENG) ENGINE OIL PRESSURE INDICATOR SWITCH (MOUNTED ON CENTER OF OIL PAN) EXHAUST GAS RECIRC- ULATION VALVE (ON UPPER RIGHT REAR OF ENG) GRD GRY WIRE HOT IN RUN, BULB TEST OR START IC CNTRL IDLE AIR CONTROL (IAC) VALVE (ON TOP OF ENG, FRONT OF THROTTLE ASSEMBLY) IGN IGNITION CONTROL MODULE (TOP RIGHT SIDE OF ENG) LT BLU/BLK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLK WIRE PARK/NEUTRAL POSITION SWITCH (MOUNTED ON TOP OF TRANSAXLE) PNK WIRE PNK/BLK WIRE PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE SECONDARY AIR INJECTION PUMP (LOWER LEFT FRONT OF ENG COMPT, ON FRAME RAIL) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCC SWITCH THROTTLE POSITION SENSOR UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE YEL/BLK WIRE
