3.8l (vin l), starting circuit for Oldsmobile Silhouette I (1989-1996)
3.8l (vin l), starting circuit
ABS ENABLE RELAY
ACCY
BATTERY
BLK WIRE
BULB TEST
DIAGNOSTIC ENERGY RESERVE MODULE (DERM) (BEHIND CENTER CONSOLE)
FUSIBLE LINK (16 GA-RUST)
FUSIBLE LINK B (20 GA. RUST)
FUSIBLE LINK H (16 GA. RUST)
GENERATOR (RIGHT REAR SIDE OF ENGINE)
HOLD-IN WINDING PULL-IN WINDING
IGNITION SWITCH
LOCK OFF
POWERTRAIN CONTROL MODULE (PCM) (BELOW RIGHT SIDE OF INSTRUMENT PANEL)
PPL
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER SOLENOID SOLENOID CONTACTS
TRANSAXLE POSITION SWITCH (ON TOP OF TRANSAXLE)
YEL WIRE
