Door lock circuit, automatic door locks for Oldsmobile Silhouette I (1989-1996)
Door lock circuit, automatic door locks
AUTOMATIC DOOR LOCK MODULE (NEAR BASE OF RIGHT "A" PILLAR)
BATTERY
BLK WIRE
CONVENIENCE CENTER
CTSY FUSE
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES PWR ACCY CIRCUIT BREAKER
HOT IN RUN, BULB TEST OR START
JAMB SWITCH IN
KEY LOCK SWITCH SIGNAL UNLOCK RELAY CONTROL
LEFT DOOR JAMB SWITCH SLIDING DOOR JAMB SWITCH
LEFT DOOR LOCK SWITCH LOCK UNLOCK
LEFT DOOR/ IGNITION KEY IN
LEFT KEY LOCK SWITCH
LIFTGATE LOCK MOTOR
LOCK
LOCK POWER DOOR LOCK RELAY
LOCK RELAY CONTROL
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK POSITION INPUT
PNK IGNITION WIRE
PNK WIRE
RIGHT DOOR LOCK MOTOR LEFT DOOR LOCK MOTOR
RIGHT DOOR LOCK SWITCH UNLOCK
RIGHT KEY LOCK SWITCH
SLIDING DOOR CONTACT SWITCH
SLIDING DOOR LOCK MOTOR
TAN WIRE
TRANSAXLE POSITION SWITCH
TURN-B/U FUSE
UNLOCK
WHT WIRE
