Oldsmobile Ninety-Eight XI (1991-1996) Charging circuit

AMP IND. BATTERY BLK WIRE BRN WIRE ENGINE RUNNING INPUT FIELD (ROTOR) GENERATOR (TOP RIGHT SIDE OF ENGINE) GROUND DISTRIBUTION HOT IN RUN, BULB TEST OR START I/P FUSE BLOCK INSTRUMENT CLUSTER MULTI- FUNCTION CHIME CONTROL MODULE PNK WIRE POWER DISTRIBUTION RECTIFIER BRIDGE RED WIRE REGULATOR SOLID STATE STARTER SOLENOID STATOR
