Oldsmobile Ninety-Eight XI (1991-1996) Instrument illumination circuit

ASHTRAY LAMP BLK WIRE BLK/WHT WIRE BRN WIRE DK GRN WIRE DRIVER DOOR FLOODLIGHT FUEL DOOR RELEASE SWITCH GRY WIRE HEAD PARK LAMP SWITCH HEAD/PARK LAMP SWITCH HEATER AND A/C CONTROL ASSEMBLY HOT AT ALL TIMES FUSE I/P FUSE BLOCK I/P FUSE BLOCK FUSE INSTRUMENT CLUSTER JUNCTION LAMP CONTROL MODULE (CENTER OF I/P) LEFT POWER SEAT SWITCH NCA WIRE OFF HEAD PARK ORG/ WIRE PANEL DIMMER MODULE (BEHIND CENTER OF I/P) PARKLAMP RELAY POSITION L (IN RELAY CENTER) PASSENGER CLIMATE CONTROL ASSEMBLY PASSENGER DOOR FLOODLIGHT PPL/WHT WIRE PRNDL ILLUMI- NATION LAMPS (W/ CONSOLE) RADIO RIGHT POWER SEAT SWITCH SIR COIL ASSEMBLY STEERING WHEEL AND HVAC SWITCHES TRACTION CONTROL/ COMPUTER COMMAND RIDE ASSEMBLY TRUNK RELEASE SWITCH VF DIM INPUT W/ TWILIGHT SENTINEL/ DAYTIME RUNNING LIGHTS ONLY YEL WIRE
