Oldsmobile Ninety-Eight XI (1991-1996) remote accessory ctrl module wiring diagram
This page shows the only wiring diagram for the component.remote accessory ctrl module, which is found in the car Oldsmobile Ninety-Eight XI (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
remote accessory ctrl module wiring diagram (1 of 1)
A/C COMP CLUTCH
A/C COMP CLUTCH DIODE
A/C PRES FAN SW
ANTENNA RELAY
BLK BLK WIRE
BLK WIRE
BLK/WHT WHT/TAN WHT/TAN BLK/WHT WIRE
BLK/WHT WIRE
CRUISE CTRL SERVO
DATA LINK CONN
DIAGNOSTIC ENERGY RESERVE MODULE
FUEL PUMP RLY
HEATED OXYGEN SENS
MASS AIRFLOW SENS
MULTI/FUNCTION CHIME CTRL MODULE
PACKAGE
PARK/NEUTRAL POSITION SW
PASSENGER INTERIOR CLIMATE CONTRL LAMPS ASSY RELAY
POWERTRAIN CTRL MODULE
RELAY RELAY #2 #1
REMOTE ACCESSORY CTRL MODULE
RETAINED ACCESSORY POWER
RIGHT CORNERING LAMP
RIGHT FRONT DOOR HANDLE SW
RIGHT FRONT DOOR LOCK SW ASSY
RIGHT LUMBAR SEAT SWITCH
RIGHT SEAT SW
SUNROOF CTRL MODULE
W/ HIGH OUTPUT ENGINE
W/ REMINDER
Go to component -> Ground distribution circuit (3 of 3) -> REMOTE ACCESSORY CTRL MODULE
