Oldsmobile Ninety-Eight XI (1991-1996) computer command ride(ccr) controller wiring diagram
This page shows the only wiring diagram for the component.computer command ride(ccr) controller, which is found in the car Oldsmobile Ninety-Eight XI (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
computer command ride(ccr) controller wiring diagram (1 of 1)
BLK/WHT WIRE
BRN WIRE
CHIME MODULE
COMPUTER COMMAND RIDE(CCR) CONTROLLER
CRUISE CONTROL SERVO (LEFT SIDE OF ENGINE, RIGHT OF WHEELHOUSE)
CRUISE IND
CRUISE RELEASE SW (ON BRAKE PEDAL SUPPORT)
CRUISE SW
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
EIGHTY EIGHT& NINETY EIGHT
GRY WIRE
GRY/BLK (OR BLK) WIRE
GRY/BLK WIRE
HOT IN RUN
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER (W/ INDICATORS CLUSTER) INFORMATION CENTER (W/ GAGES CLUSTER)
LT BLU/BLK WIRE
LT GRN WIRE
MULTI/FUNCTION LEVER (TOP LEFT SIDE OF STEERING COLUMN)
NCA WIRE
OFF
ON R/A SW OFF
PARK AVENUE, LESABRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PPL
RELAY CENTER
SERVO POSITION SENSOR
SET/ COAST
TAN WIRE
TAN/WHT WIRE
TCC/ANTI/LOCK BRAKE SW (ON BRAKE PEDAL SUPPORT)
THROTTLE POSITION SENSOR
VACUUM VALVE
VEHICLE SPEED SENSOR
VENT VALVE
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit -> COMPUTER COMMAND RIDE(CCR) CONTROLLER
