Oldsmobile Eighty-Eight X (1992-1999) tcc/ antilock brake switch Wiring diagram
This page shows the only wiring diagram for the component.tcc/ antilock brake switch, which is found in the car Oldsmobile Eighty-Eight X (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tcc/ antilock brake switch (1 of 1)
A/C SOLENOID SWITCH ASSEMBLY
A/C TEMPERATURE VALVE ACTUATOR
A/C TEMPERATURE VALVE ACTUATOR (PONTIAC)
A/C TEMPERATURE VALVE ACTUATOR HEATER AND A/C CONTROL ASSEMBLY
ABS/CCR
ADAPTIVE LAMP MONITOR CONTROL MODULE
AUTO A/C-CRUISE
BASE A/C
BRN WIRE
CLG FAN/ TRANS
COMPUTER COMMAND RIDE (CCR) CONTROLLER
CRUISE CONTROL MODULE
CRUISE CONTROL SWITCH
DRIVER SELECT SHIFT SWITCH
DRIVER SELECT SHIFT SWITCH INSTRUMENT CLUSTER
ELC HEIGHT SENSOR
ELC RELAY
ELECTRONIC BRAKE AND TRACTION CONTROL MODULE
ELECTRONIC BRAKE AND TRACTION CONTROL MODULE BLOWER SPEED RELAY
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
HEAD UP DISPLAY CONTROL MODULE HEAD UP DISPLAY CONTROL SWITCH
HEATER AND A/C CONTROL ASSEMBLY
HIGH SPEED COOLANT FAN RELAY
HVAC PROGRAMMER
I/P FUSE BLOCK
LOW SPEED COOLANT FAN RELAY
NCA WIRE
OLDSMOBILE
ORG/ WIRE
PONTIAC
PONTIAC ONLY
PONTIAC SSE
RIGHT I/P POWER DISTRIBUTION CENTER
TCC/ ANTILOCK BRAKE SWITCH
W/ CENTER CONSOLE
W/ COMPUTER COMMAND RIDE W/O COMPUTER COMMAND RIDE
W/O CENTER CONSOLE
Go to component -> Power distribution circuit (5 of 6) -> TCC/ ANTILOCK BRAKE SWITCH
