Oldsmobile Eighty-Eight X (1992-1999) sig/b-u lps btsi/cor Wiring diagrams
This page contains all the electrical diagrams for the component. sig/b-u lps btsi/cor, in which he is found in the car Oldsmobile Eighty-Eight X (1992-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sig/b-u lps btsi/cor wiring diagram (1 of 2)
BLK WIRE
BRK/HZRD LPS
BRN WIRE
CENTER I/P CROSS- CHANNEL)
CRUISE/ SHIFT INTERLOCK BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
FROM CENTER I/P CROSS-CHANNEL)
HAZARD FLASHER (BEHIND I/P, RIGHT OF STEERING COLUMN SUPPORT)
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
INSTRUMENT CLUSTER
LEFT REAR SIDE MARKER LAMP
LEFT TAIL/ STOP/ TURN LAMPS
LEFT TURN INDICATOR
LEFT TURN SWITCH
LICENSE LAMPS
LT BLU WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL PNK 4 5 6 WIRE
RIGHT REAR SIDE MARKER LAMP
RIGHT TAIL/ STOP/ TURN LAMPS
RIGHT TURN INDICATOR
RIGHT TURN SWITCH
SIG/B-U LPS BTSI/COR
TURN FLASHER (ATTACHED TO SOUND INSULATOR)
TURN/ HAZARD SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit, with adaptive lamp monitor (2 of 2) -> SIG/B-U LPS BTSI/COR
sig/b-u lps btsi/cor wiring diagram (2 of 2)
BLK WIRE
BRK/HZRD LPS
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP
CENTER I/P CROSS- CHANNEL)
CRUISE/ SHIFT INTERLOCK BRAKE SWITCH (ON BRAKE PEDAL SUPPORT)
DK BLU WIRE
DK GRN WIRE
FROM CENTER I/P CROSS-CHANNEL)
HAZARD FLASHER (BEHIND I/P, RIGHT OF STEERING COLUMN SUPPORT)
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN RUN, BULB TEST OR START
I/P FUSE BLOCK
INSTRUMENT CLUSTER
LEFT REAR SIDE MARKER LAMP
LEFT TAIL/ STOP/ TURN LAMPS
LEFT TURN INDICATOR
LEFT TURN SWITCH
LICENSE LAMPS
LT BLU WIRE
ORG/ WIRE
PNK WIRE
PPL
RIGHT REAR SIDE MARKER LAMP
RIGHT TAIL/ STOP/ TURN LAMPS
RIGHT TURN INDICATOR
RIGHT TURN SWITCH
SIG/B-U LPS BTSI/COR
TURN FLASHER (ATTACHED TO SOUND INSULATOR)
TURN/ HAZARD SWITCH ASSEMBLY
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, without adaptive lamp monitor (2 of 2) -> SIG/B-U LPS BTSI/COR
