Oldsmobile Eighty-Eight X (1992-1999) passenger climate controller Wiring diagram
This page shows the only wiring diagram for the component.passenger climate controller, which is found in the car Oldsmobile Eighty-Eight X (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger climate controller (1 of 1)
A OR B
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH DIODE
BLK WIRE
BODY CONTROL MODULE (MALL)
FRONT HEATED OXYGEN SENSOR REAR HEATED OXYGEN SENSOR
HEADLAMP RELAY
HEADS-UP DISPLAY CONTROL MODULE (PONTIAC W/ HUD)
HVAC PROGRAMMER (BUICK, PONTIAC)
LAMP CONTROL MODULE (LCM) (BUICK)
NCA WIRE
PARKLAMP RELAY (OLDS)
PASSENGER CLIMATE CONTROLLER
PONTIAC
POWER ANTENNA RELAY (OLDS, PONTIAC)
POWER WINDOW, SUNROOF RELAY
RIGHT FOG LAMP (OLDS)
RIGHT FRONT DOOR COURTESY LAMP (PONTIAC)
RIGHT FRONT LUMBAR SWITCH (OLDS)
RIGHT FRONT POWER SEAT SWITCH (OLDS)
RIGHT FRONT POWER SEAT SWITCH (OLDS, BUICK)
RIGHT FRONT SIDE MARKER LAMP (PONTIAC)
RIGHT I/P POWER DISTRIBUTION CENTER
RIGHT OUTSIDE MIRROR (PONTIAC)
SUNROOF CONTROL MODULE (PONTIAC)
Go to component -> Ground distribution circuit (3 of 6) -> PASSENGER CLIMATE CONTROLLER
