Oldsmobile Eighty-Eight X (1992-1999) olds, buick pontic Wiring diagram
This page shows the only wiring diagram for the component.olds, buick pontic, which is found in the car Oldsmobile Eighty-Eight X (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram olds, buick pontic (1 of 1)
A/C FEEDBACK FUSE 11
A/C FUSE
AIR CONDITIONING SYSTEM
BLOWER RELAY
BODY CONTROL MODULE (MALL)
BRAKE LPS/HZD
BUICK OLDSMOBILE
CRUISE/SHIFT INTERLOCK/ BRAKE SWITCH
CTSY LPS/ PW MRRS
DOOR LKS FUSE 1
FOG LAMP RELAY (OLDS, PONTIAC)
FOG LPS
FROM ELC FUSE (DIAGRAM 1 OF 6)
FROM MISC LGT FUSE (DIAGRAM 1 OF 6)
HAZARD FLASHER
HEADLAMP SWITCH (PONTIAC)
HORN FUSE 3
HORN RELAY
HORNS/TRUNK MISC FUSE
HVAC PROGRAMMER
I/P FUSE BLOCK
IGN SW ACCY FUSE
LEFT FRONT DOOR LOCK ISOLATION RELAY
LEFT FRONT MIRROR SWITCH
LEFT FRONT MIRROR SWITCH BODY CONTROL MODULE (MALL)
LEFT SEAT SWITCH (OLDSMOBILE)
LUGGAGE COMPARTMENT LID RELEASE RELAY
NCA WIRE
OLDS
OLDS, BUICK PONTIC
ORG/ WIRE
PARK LPS/INT LPS
PASS-KEY II DECODER MODULE
PCM/VAT FUSE
PONTIAC
POWER ANTENNA RELAY (OLDS, PONTIAC)
POWER- TRAIN CONTROL MODULE
PPL
PWR WDO/ SUNROOF RELAY
PWR WDO/SR CIRCUIT BREAKER
RED WIRE
REMOTE FUNCTION ACTUATOR B MODULE
RIGHT I/P POWER DISTRIBUTION CENTER
RIGHT MAXI FUSE BLOCK
SEAT RECLINE SWITCH CONSOLE SEAT SWITCH (PONTIAC)
TO IGNITION SWITCH (DIAGRAM 4 OF 6)
TO LAMP CONTROL MODULE (DIAGRAM 3 OF 6)
TO RETAINED ACCESSORY POWER RELAY (DIAGRAM 4 OF 6)
TRK/REL/PWR ANT/RAC LKS FUSE 2
W/ DUAL POWER MIRRORS
W/ DUAL ZONE/ ELECTRONIC AUTOMATIC A/C W/ MANUAL/ ELECTRONIC A/C
W/ LEFT POWER MIRROR
Go to component -> Power distribution circuit (2 of 6) -> OLDS, BUICK PONTIC
