Oldsmobile Eighty-Eight X (1992-1999) left rear door latch switch right front door lock switch Wiring diagram

BLK WIRE BLK/WHT WIRE BLU WIRE BODY CONTROL MODULE (MALL) (RIGHT SIDE OF I/P) CHIME CONSOLE STORAGE LAMP CONSOLE STORAGE LAMP SWITCH COURTESY COVER SWITCH CTSY PWR MIR DIMMER SWITCH DK BLU WIRE DOOR OPEN IN DR LKS FUSE 1 FRONT DOME/ READING LAMPS GND BAT CRTSY (+) BAT CRTSY (-) GRN WIRE HEADLAMP SWITCH HOT AT ALL TIMES HOT IN ACC, RUN HOT IN RUN, BULB TEST OR START I/P COMPARTMENT LAMP I/P FUSE BLOCK I/P FUSE BLOCK RADIO INSIDE REAR VIEW MAP LAMPS INTERIOR LAMP CONTROL LEFT FOOTWELL COURTESY LAMP LEFT FRONT DOOR COURTESY LAMPS LEFT FRONT DOOR HANDLE SWITCH LEFT FRONT DOOR LOCK SWITCH LEFT FRONT DOOR WARNING LAMPS LEFT FRONT VANITY MIRROR LEFT REAR DOOR LAMPS LEFT REAR DOOR LATCH SWITCH RIGHT FRONT DOOR LOCK SWITCH LEFT REAR RAIL COURTESY/ READING LAMP (W/ ASTRO- ROOF) LT GRN WIRE LT GRN/BLK WIRE LUGGAGE COMPART- MENT LID LATCH SWITCH LUGGAGE COMPARTMENT LAMP NCA WIRE ORG/ WIRE ORG/BLK WIRE PNK IGN DOOR OPEN DOOR OPEN INT LMP IN DOOR HNDL 49 126 1393 WIRE PNK WIRE REMOTE FUNCTION ACTUATOR (RFA) MODULE (RIGHT SIDE OF I/P) RIGHT FOOTWELL COURTESY LAMP RIGHT FRONT DOOR COURTESY LAMPS RIGHT FRONT DOOR HANDLE SWITCH RIGHT FRONT DOOR WARNING LAMPS RIGHT FRONT VANITY MIRROR RIGHT I/P POWER DISTRIBUTION CENTER RIGHT REAR DOOR LAMPS RIGHT REAR DOOR LATCH SWITCH RIGHT REAR RAIL COURTESY/ READING LAMP (W/ ASTRO- ROOF) TAN WIRE WARNING WHT WIRE YEL WIRE
