Oldsmobile Eighty-Eight X (1992-1999) junc- tion conn- ector wiring diagram
This page shows the only wiring diagram for the component.junc- tion conn- ector, which is found in the car Oldsmobile Eighty-Eight X (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
junc- tion conn- ector wiring diagram (1 of 1)
BLK WIRE
DRIVE UNIT
HOT AT ALL TIMES CTSY/PWR MIR
I/P FUSE BLOCK
JUNC- TION CONN- ECTOR
LEFT FRONT OUTSIDE MIRROR SWITCH
LEFT OUTSIDE MIRROR
LEFT/ RIGHT MOTOR
LT BLU WIRE
LT GRN WIRE
LT MIRROR POSITION SWITCH
MIRROR POSITION SWITCH
NCA WIRE
ORG/ WIRE
PPL/WHT WIRE
RED/WHT WIRE
RIGHT OUTSIDE MIRROR
UP/ DOWN MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> JUNC- TION CONN- ECTOR
