Oldsmobile Eighty-Eight X (1992-1999) interior lps Wiring diagram
This page shows the only wiring diagram for the component.interior lps, which is found in the car Oldsmobile Eighty-Eight X (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior lps (1 of 1)
ASHTRAY LAMP
BRN WIRE
CONNECTOR BREAKOUT)
ENGINE COMPARTMENT LAMP
FROM PARK LPS FUSE (DIAGRAM 2 OF 6)
HEAD LAMP SWITCH RADIO
HEAD- LAMP SWITCH
HEADS-UP DISPLAY CONTROL MODULE
HEATER AND A/C CONTROL ASSEMBLY
I/P FUSE BLOCK
INSTRUMENT CLUSTER
INTERIOR LAMP CONTROL
INTERIOR LPS
LAMP CONTROL MODULE
LAMP DIMMER SWITCH
LEFT FRONT DOOR COURTESY LAMP
NCA WIRE
OLDSMOBILE
ORG/ WIRE
PANEL DIMMER MODULE
PARK LAMP RELAY
PARK LAMPS
PERIMETER LT
PONTIAC
PPL
RADIO
REMOTE DIMMER MODULE
RIGHT FRONT DOOR COURTESY LAMP
RIGHT I/P POWER DISTRIBUTION CENTER
TAN WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> INTERIOR LPS
