Oldsmobile Eighty-Eight X (1992-1999) engine oil pressure switch Wiring diagram
This page shows the only wiring diagram for the component.engine oil pressure switch, which is found in the car Oldsmobile Eighty-Eight X (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine oil pressure switch (1 of 1)
BATTERY
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
BLOWER CONTROL MODULE HVAC BLOWER MOTOR
DATA LINK CONNECTOR
ENGINE COOLANT LEVEL SWITCH
ENGINE OIL LEVEL SWITCH
ENGINE OIL PRESSURE SWITCH
FROM JUNCTION
FROM TRACTION CONTROL SWITCH (DIAGRAM 2 OF 6)
FUEL LEVEL MODULE
FUEL PUMP RELAY
HIGH SPEED BLOWER RELAY (PONTIAC, OLDS W/ MANUAL A/C, BUICK W/ ELECTRIC A/C)
I/P CLUSTER
I/P CLUSTER (OLDS)
I/P CROSS CHANNEL)
IGNITION CONTROL MODULE
MAP SENSOR (PONTIAC)
MASS AIR FLOW (MAF SENSOR)
OLDSMOBILE
PARK/ NEUTRAL POSITION SWITCH
PASS-KEY II DECODER MODULE
POWERTRAIN CONTROL MODULE
PRNDL ILLUM. LAMP (OLDS)
RIGHT CORNERING LAMP
RIGHT FRONT PARK/ TURN LIGHT
RIGHT HIGH BEAM HEADLAMP
RIGHT HIGH BEAM HEADLIGHT (OLDS AND PONTIAC)
RIGHT HORN
RIGHT LOW BEAM HEADLAMP
RIGHT LOW BEAM HEADLIGHT (OLDS AND PONTIAC)
SHIFT CONTROL INDIC LAMP
WHT/ BLK WIRE
Go to component -> Ground distribution circuit (1 of 6) -> ENGINE OIL PRESSURE SWITCH
