Power door lock circuit for Oldsmobile Cutlass VI (1997-1999)
Power door lock circuit
BATTERY (B+)
BLK WIRE
BLK/WHT WIRE
DOOR LK RLY
DOOR LOCK FUSE
DOOR LOCK RELAY
DOOR UNLOCK RELAY
GROUND SPLICE PACK (LEFT END OF DASH)
GROUND SPLICE PACK (RIGHT SIDE OF REAR PACKAGE SHELF)
GRY WIRE
HORNS SYSTEM
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR LOCK SWITCH
LEFT REAR DOOR LOCK ACTUATOR
LFT DOOR LK MTR DOOR UNLK RLY HORN CHIRP INTERIOR LTS CTRL
LID RELEASE OUT LID RELEASE PWR
LOCK
LT BLU WIRE
LT BLU/BLK WIRE
ORG/ WIRE
PROGRAMMING CONNECTOR (RIGHT SIDE OF TRUNK)
PROGRAMMING TRANS POS IN GROUND
REMOTE CONTROL DOOR LOCK RECEIVER (RFA) (UNDER REAR PACKAGE SHELF)
RIGHT FRONT DOOR LOCK ACTUATOR
RIGHT FRONT DOOR LOCK SWITCH
RIGHT REAR DOOR LOCK ACTUATOR
TAN WIRE
TRUNK REL/RFA FUSE
TRUNK, TAIL- GATE, FUEL DOORS SYSTEM
UNLOCK
W/ KEYLESS ENTRY SYSTEM
W/ RKE
W/O KEYLESS ENTRY SYSTEM
WHT WIRE
WIRING HARNESS JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
YEL WIRE
