Oldsmobile Cutlass VI (1997-1999) step dim input Wiring diagram

2.4L L4 3.1L V6 5 VOLTS A/C BFC FUSE A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH DIODE A/C COMPRESSOR CLUTCH RELAY A/C DISABLE A/C ON IND A/C REFIGERANT PRESSURE SENSOR (ON FRONT OF ENGINE COMPT) A/C REQ INPUT A/C REQUEST IGN A/C REQUEST LOGIC A/C SWITCH AIR TEMP LOGIC AIR TEMPERATURE ACTUATOR (TOP RIGHT SIDE OF DASH) BATTERY BLK WIRE BLK/WHT WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLOWER RESISTOR ASSEMBLY (BELOW RIGHT SIDE OF DASH) BLOWER SWITCH BODY FUNCTION CONTROLLER (BELOW RIGHT SIDE OF DASH) BRN WIRE CLUTCH RLY CTRL COOL FAN 1 FUSE COOL FAN 2 FUSE DEFOG ON IND DEFOG REQUEST LOGIC DEFOG SWITCH DEFOGGER SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE FAN CONTROL RELAY 1 FAN CONTROL RELAY 2 GROUND GRY WIRE HEATER, A/C CONTROL ASSEMBLY HI BLO MOT FUSE HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START HOT IN RUN RIGHT I/P JUNCTION BLOCK HVAC BLOWER FUSE HTR A/C IGN FUSE IGN DEFOG REL CTRL STEP DIM INPUT GROUND IGN HTR OUT GROUND IGNITION ILLUM LEFT COOLING FAN MOTOR LEFT FAN CTRL LEFT I/P JUNCTION BLOCK LEFT I/P JUNCTION BLOCK IPC/HVAC BATT FUSE LT BLU WIRE LT GRN WIRE MODE CONTROL RELAY OFF LO ORG/ WIRE POWERTRAIN CONTROL MODULE (BELOW LEFT SIDE OFDASH, NEXT TO STEERING COLUMN) PPL RED WIRE RED/BLK WIRE RIGHT COOLING FAN MOTOR RIGHT FAN CTRL SENSOR GROUND SENSOR SIGNAL SER DATA CLS 2 STEP DIM INPUT TAN WIRE TEMP REQ UNDERHOOD JUNCTION BLOCK WHT WIRE YEL WIRE
