Shift interlock circuit for Oldsmobile Bravada III (2001-2004)
Shift interlock circuit
A/T SHIFT LOCK CONTROL SOLENOID
B/U LAMP FUSE
BLK WIRE
BTSI FUSE
DK GRN WIRE
HOT IN RUN, START
LT GRN WIRE
LT GRN/BLK WIRE
PARK LOCK SOLENOID
PARK/ NEUTRAL POSITION (PNP) SWITCH (ON LEFT SIDE OF TRANSMISSION)
PNK WIRE
TCC/BRAKE SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TRANSMISSION CONTROL
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
