Power top/sunroof circuits, short wheel base for Oldsmobile Bravada III (2001-2004)
Power top/sunroof circuits, short wheel base
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
BRN WIRE
CLOSE OPEN
DK BLU WIRE
DK BLU/RED WIRE
DK GRN WIRE
GND CLOSE
HOT AT ALL TIMES
HOT WITH RAP ENERGIZED
LT BLU WIRE
NCA WIRE
OPEN CLOSE
ORG/ WIRE
PPL
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
SUN ROOF MODULE
SUN ROOF MOTOR (ABOVE HEADLINER, AT REAR OF SUNROOF ASSEMBLY)
SUN ROOF SWITCH
SUNROOF FUSE 28
WHT WIRE
YEL/RED WIRE
