Oldsmobile Bravada III (2001-2004) Instrument cluster circuit

21 43 LOW REF OIL TEMP SEND 4 3 PERSONAL- IZATION 4 3 TRIP 7 32 MIL CTRL VSS 8 BULBS ABS IND. AIR BAG IND AIR SUSPENSION COMPRESSOR ASSEMBLY (ON LEFT REAR FRAME RAIL, NEAR SPARE TIRE) BATTERY IND BLK WIRE BLK/WHT WIRE BRAKE IND BRN WIRE BRN/WHT WIRE CHANGE ENG OIL IND CHECK GAUGES IND CLASS 2 CLASS 2 COMPUTER DATA LINES SYSTEM CRUISE IND DIC FUEL SIG DIC SET/RESET DIC SW SIG DIC TOGGLE SW DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENG SPEED ENG SPEED SIG ENGINE OIL LEVEL, TEMPERATURE SENSOR (ON RIGHT SIDE OF ENG BLOCK) ENGINE OIL PRESSURE SWITCH (ON RIGHT SIDE OF ENG BLOCK) FUEL FUEL GAUGE FUEL PUMP, SENDER ASSEMBLY (INSIDE FUEL TANK) GRY WIRE HIGH BEAM IND HOT AT ALL TIMES HOT IN RUN OR START IGN 1 IGN E FUSE 22 ILLUMINATION INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL INSTRUMENT CLUSTER LEFT TURN LEFT TURN IND LO COOLANT LO WASHER FLUID LOGIC LOW FUEL IND LOW REF LT BLU WIRE NCA WIRE NOT USED OIL GAUGE OIL LEVEL SW OIL PRESS SW ORG/ WIRE ORG/BLK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (ON UPPER LEFT SIDE OF ENG) PPL PPL FUEL LEVEL PPL LOW REF REDUCE ENG POWER IND RIGHT TURN RIGHT TURN IND SEAT BELT IND SECURITY IND SELECT SERVICE ENGINE SOON IND SHIFT IND SPEEDOMETER STEERING WHEEL CONTROL ASSEMBLY TACHOMETER TAILGATE AJAR IND TAN/BLK WIRE TEMP GAUGE TRIP ODOMETER DIC VOLTS GAUGE VSS WHT WIRE WINDSHIELD WASHER FLUID LEVEL SWITCH (IN WINDSHIELD WASHER FLUID RESERVOIR) YEL WIRE
