Back-up lamps circuit for Oldsmobile Bravada III (2001-2004)
Back-up lamps circuit
13 12 20 TR SW P TR SW B TR SW C
B/U LMP VOLT
BACKUP FUSE 27
BACKUP LAMP
BATTERY
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
DK GRN WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
LEFT TAILLAMP ASSEMBLY
LT GRN WIRE
MIRRORS SYSTEM (AUTOMATIC DAY/ NIGHT MIRROR)
NCA WIRE
PARK/ NEUTRAL POSITION SWITCH
PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION)
PNK WIRE
POWERTRAIN CONTROL MODULE (ON UPPER LEFT SIDE OF ENGINE)
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
REAR FUSE BLOCK (BELOW LEFT REAR SEAT) TBC 5 FUSE 32
RIGHT TAILLAMP ASSEMBLY BACKUP LAMP
SERIAL DATA
TR SW A
TRAILER CONNECTOR (LOWER LEFT SIDE OF ENGINE BLOCK)
TRLR B/U
UNDER- HOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
