Oldsmobile Bravada III (2001-2004) Automatic a/c circuit

230 751 LPS DIMMING CTRL GROUND AIR TEMPERATURE ACTUATOR (LEFT) (BEHIND LEFT CENTER OF DASH) AIR TEMPERATURE ACTUATOR (RIGHT) (BEHIND RIGHT CENTER OF DASH) AMBIENT AIR TEMPERATURE SENSOR (ON LEFT CENTER OF RADIATOR SUPPORT) AMBIENT LIGHT AMBIENT LIGHT/ SUNLOAD SENSOR ASSEMBLY (TOP CENTER OF DASH) BLK WIRE BLK/WHT WIRE BLOWER FUSE BLOWER MOTOR BLOWER MOTOR CONTROL PROCESSOR BLWR MTR SPD CTRL INSIDE AIR TEMP CTRL LOW REFERENCE BRN WIRE BRN/WHT WIRE CLASS 2 A/C COMP STATUS DEFROST ACTUATOR (UPPER LEFT CENTER OF DASH) DK BLU WIRE DK GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HVAC (B+) FUSE HVAC 1 FUSE HVAC CONTROL MODULE INSIDE AIR TEMPERATURE SENSOR (TOP OF LEFT "B" PILLAR, BEHIND TRIM) LEFT SENSOR LOWER LEFT AIR TEMPERATURE SENSOR (BEHIND LOWER LEFT OF DASH, ON AIR DUCT) LOWER RIGHT AIR TEMPERATURE SENSOR (BEHIND LOWER RIGHT OF DASH, ON AIR DUCT) LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE MODE ACTUATOR (UPPER LEFT CENTER OF DASH) NCA WIRE ORG/ WIRE PPL PPL/WHT WIRE REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RECIRULATION ACTUATOR (UPPER RIGHT SIDE OF DASH) RED WIRE RIGHT SENSOR RUN WIRE SOLID STATE TAN WIRE TAN/BLK WIRE UNDER- HOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) UPPER LEFT AIR TEMPERATURE SENSOR (BEHIND UPPER LEFT CENTER OF DASH) UPPER RIGHT AIR TEMPERATURE SENSOR (BEHIND UPPER RIGHT CENTER OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE

43 60 57 42 59 41 54 14 HIGH SPD MAF LOW REF A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C FUSE IGN E FUSE A/C LOW PRESSURE SWITCH (AT RIGHT REAR OF ENG COMPT, ON ACCUMULATOR) A/C REFRIGERENT PRESSURE SENSOR (ON HIGH PRESSURE LINE NEAR A/C COMP) AM/FM AMBIENT LIGHT SENS BLK WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) COMP RLY CNTRL SERIAL DATA A/C PRESS SIG COOLING FAN COOLING FAN RELAY DATA LINK CONNECTOR (ON BOTTOM OF LEFT SIDE OF DASH) DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENG FAN FUSE FAN DN FAN UP GRY WIRE GRY/WHT WIRE HALL SENSOR HOT AT ALL TIMES HOT IN RUN OR START INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LOW REF LOW REFERENCE LT BLU/BLK WIRE LT GRN WIRE LT SUNLOAD SENS SIG MODE NCA WIRE POWERTRAIN CONTROL MODULE (UPPER LEFT SIDE OF ENGINE) PPL RADIO CTRL SIG RED/BLK WIRE RT SUNLOAD SENS SIG SERIAL DATA STAR CONNECTOR 1 (ON LOWER LEFT SIDE OF DASH) STEERING WHEEL CONTROL SWITCHES SUPPLY VOLTAGE TEMP DN TEMP UP UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) VOL DN VOL UP WHT WIRE WHT/BLK WIRE WINDSHIELD WASHER PUMP BREAKOUT)
