Oldsmobile Bravada III (2001-2004) lr spkr out + lr spkr out - lf mid spkr out + lf mid spkr out - Wiring diagram
This page shows the only wiring diagram for the component.lr spkr out + lr spkr out - lf mid spkr out + lf mid spkr out -, which is found in the car Oldsmobile Bravada III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lr spkr out + lr spkr out - lf mid spkr out + lf mid spkr out - (1 of 1)
5 6 7 8 9 10 AMP CLASS 2 SERIAL DATA
AMP FUSE 11
AUDIO AMPLIFIER (BEHIND RIGHT SIDE PANEL OF THE REAR COMPARTMENT)
BARE
BARE DRAIN WIRE
BLK WIRE
BRN WIRE
DATA LINES
DK BLU WIRE
DK GRN WIRE
DRAIN WIRE SUPPLY VOLTAGE
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT I/P SPEAKER
LEFT REAR DOOR SPEAKER
LR SPKR OUT + LR SPKR OUT - LF MID SPKR OUT + LF MID SPKR OUT -
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NOISE REDUCTION MICROPHONE (IN UPPER CONSOLE)
ORG/ WIRE
ORG/BLK WIRE
REAR FUSE BLOCK (BENEATH LEFT REAR SEAT)
RF MID SPKR OUT + RF MID SPKR OUT - RR SPKR OUT - RR SPKR OUT +
RF SPKR OUT - LF SPKR OUT + LF SPKR OUT - RF SPKR OUT +
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT I/P SPEAKER
RIGHT REAR DOOR SPEAKER
TAN WIRE
YEL WIRE
Go to component -> Premium sound radio circuit (2 of 2) -> LR SPKR OUT + LR SPKR OUT - LF MID SPKR OUT + LF MID SPKR OUT -
