Oldsmobile Bravada III (2001-2004) left rear courtesy reading lamp Wiring diagram
This page shows the only wiring diagram for the component.left rear courtesy reading lamp, which is found in the car Oldsmobile Bravada III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear courtesy reading lamp (1 of 1)
BLK WIRE
CARGO LAMP
COURTESY
FROM REAR FUSE BLOCK (DIAGRAM 1 OF 2)
GRY WIRE
LEFT CENTER COURTESY READING LAMP
LEFT FRONT COURTESY/ READING LAMP
LEFT FRONT VANITY MIRROR LAMP
LEFT REAR COURTESY READING LAMP
ORG/ WIRE
READING
RIGHT CENTER COURTESY/ READING LAMP
RIGHT FRONT COURTESY READING LAMP
RIGHT FRONT VANITY MIRROR LAMP
RIGHT REAR COURTESY/ READING LAMP
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT REAR COURTESY READING LAMP
