Oldsmobile Bravada III (2001-2004) coolant bypass valve Wiring diagram
This page shows the only wiring diagram for the component.coolant bypass valve, which is found in the car Oldsmobile Bravada III (2001-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant bypass valve (1 of 1)
A/C LOW PRESSURE SWITCH
BARE
BARE (W/ PREMIUM PERFORMANCE ENHANCED AUDIO SPEAKER SYSTEM)
BATTERY
BLK WIRE
BLK/WHT WIRE
BREAKOUT)
COOLANT BYPASS VALVE
COOLING FAN TETHER
DATA LINK CONNECTOR
FRONT PASSENGER DOOR MODULE (FPDM)
HAZARD LAMP SWITCH
HEADLAMP DIMMER SWITCH
HEADLAMP WASHER FLUID PUMP
HORN ASSEMBLY
HVAC MODULE
IGNITION COIL 1
IGNITION COIL 3
IGNITION COIL 4 IGNITION COIL 5
IGNITION COIL 6 IGNITION COIL 2
IGNITION KEY ALARM SWITCH
INFLATABLE RESTRAINT SENSING AND DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
NCA WIRE
ONSTAR MICROPHONE GROUND SHIELD 2 PASSENGER SEAT
ONSTAR MODULE
RADIO
RADIO GROUND SHIELD
REAR WINDOW WASHER PUMP
RIGHT CORNERING LAMP (IF EQUIPPED)
RIGHT FRONT FOG LAMP
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP LEVELING ACTUATOR (IF EQUIPPED)
RIGHT REAR MINIWEDGE (DOOR JAMB SWITCH)
RIGHT REAR WINDOW SWITCH
TAN WIRE
TRANSFER CASE SHIFT CONTROL MODULE
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT)
UNDERHOOD LAMP
W/ ALL WHEEL DRIVE
W/ DRIVER INFORMATION CENTER DISPLAY
W/ FRONT AND SIDE, DRIVER AND PASSENGER INFLATABLE RESTRAINT SYSTEM SEAT)
W/ HIGH PRESSURE HEADLAMP WASHER
W/ WIRING PROVISIONS
WHT WIRE
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/ WASHER SWITCH
WINDSHILED WASHER FLUID LEVEL SWITCH
WINDSHILED WASHER FLUID PUMP
Go to component -> Ground distribution circuit (1 of 4) -> COOLANT BYPASS VALVE
