Oldsmobile Bravada III (2001-2004) close open Wiring diagrams
This page contains all the electrical diagrams for the component. close open, in which he is found in the car Oldsmobile Bravada III (2001-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
close open wiring diagram (1 of 2)
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
BRN WIRE
CLOSE OPEN
DK BLU WIRE
DK BLU/RED WIRE
DK GRN WIRE
GND CLOSE
HOT AT ALL TIMES
HOT WITH RAP ENERGIZED
LT BLU WIRE
NCA WIRE
OPEN CLOSE
ORG/ WIRE
PPL
RAP RELAY 22
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
SUN ROOF MODULE (ABOVE HEADLINER, AT REAR OF SUN ROOF ASSEMBLY)
SUN ROOF SWITCH
SUN-ROOF MOTOR
SUNROOF FUSE 28
VENT WDO FUSE 20
WHT WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuits, long wheel base -> CLOSE OPEN
close open wiring diagram (2 of 2)
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
BRN WIRE
CLOSE OPEN
DK BLU WIRE
DK BLU/RED WIRE
DK GRN WIRE
GND CLOSE
HOT AT ALL TIMES
HOT WITH RAP ENERGIZED
LT BLU WIRE
NCA WIRE
OPEN CLOSE
ORG/ WIRE
PPL
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
SUN ROOF MODULE
SUN ROOF MOTOR (ABOVE HEADLINER, AT REAR OF SUNROOF ASSEMBLY)
SUN ROOF SWITCH
SUNROOF FUSE 28
WHT WIRE
YEL/RED WIRE
Go to component -> Power top/sunroof circuits, short wheel base -> CLOSE OPEN
