Oldsmobile Bravada III (2001-2004) 230 751 lps dimming ctrl ground Wiring diagram

230 751 LPS DIMMING CTRL GROUND AIR TEMPERATURE ACTUATOR (LEFT) (BEHIND LEFT CENTER OF DASH) AIR TEMPERATURE ACTUATOR (RIGHT) (BEHIND RIGHT CENTER OF DASH) AMBIENT AIR TEMPERATURE SENSOR (ON LEFT CENTER OF RADIATOR SUPPORT) AMBIENT LIGHT AMBIENT LIGHT/ SUNLOAD SENSOR ASSEMBLY (TOP CENTER OF DASH) BLK WIRE BLK/WHT WIRE BLOWER FUSE BLOWER MOTOR BLOWER MOTOR CONTROL PROCESSOR BLWR MTR SPD CTRL INSIDE AIR TEMP CTRL LOW REFERENCE BRN WIRE BRN/WHT WIRE CLASS 2 A/C COMP STATUS DEFROST ACTUATOR (UPPER LEFT CENTER OF DASH) DK BLU WIRE DK GRN WIRE GROUND GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT IN HVAC (B+) FUSE HVAC 1 FUSE HVAC CONTROL MODULE INSIDE AIR TEMPERATURE SENSOR (TOP OF LEFT "B" PILLAR, BEHIND TRIM) LEFT SENSOR LOWER LEFT AIR TEMPERATURE SENSOR (BEHIND LOWER LEFT OF DASH, ON AIR DUCT) LOWER RIGHT AIR TEMPERATURE SENSOR (BEHIND LOWER RIGHT OF DASH, ON AIR DUCT) LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE MODE ACTUATOR (UPPER LEFT CENTER OF DASH) NCA WIRE ORG/ WIRE PPL PPL/WHT WIRE REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RECIRULATION ACTUATOR (UPPER RIGHT SIDE OF DASH) RED WIRE RIGHT SENSOR RUN WIRE SOLID STATE TAN WIRE TAN/BLK WIRE UNDER- HOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) UPPER LEFT AIR TEMPERATURE SENSOR (BEHIND UPPER LEFT CENTER OF DASH) UPPER RIGHT AIR TEMPERATURE SENSOR (BEHIND UPPER RIGHT CENTER OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE
