Electrochromic mirror circuit for Oldsmobile Bravada II (1995-2001)
Electrochromic mirror circuit
AUTOMATIC INSIDE DAY-NIGHT MIRROR
B/U LAMP FUSE 25
BLK WIRE
BRN WIRE
C/M
FUSE 21
GRN WIRE
GRY WIRE
HOT IN RUN
HOT IN RUN OR START
I/P FUSE BLOCK (ON LEFT SIDE OF DASH)
INTERIOR LAMPS SYSTEM
LT (SEE NOTE)
LT GRN WIRE
NCA WIRE
NOTE:
OFF
PHOTO SENSOR
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER, LOGIC CIRCUITS
SPLICE PACK
UNDERHOOD BUSSED ELECTRICAL CENTER (UBEC) (ON TOP OF LEFT FRONT FENDER WALL)
VEH B/U FUSE 12
