Power door lock circuit for Oldsmobile Bravada II (1995-2001)

1 2 3 4 BATTERY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (UNDER DASH, ON HEATER CASE) BODY RELAY BLOCK BODY RELAY BLOCK (BEHIND LEFT SIDE OF DASH, NEAR I/P FUSE BLOCK) DOOR LOCK RELAY DOOR UNLOCK RELAY DR UNLK RLY DR LK RLY DRIVER DOOR UNLOCK RELAY DRV DR UNLK RLY ENDGATE OR LIFTGATE LOCK CYLINDER SWITCH GROUND GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK LEFT DOOR LOCK AND WINDOW SWITCH LEFT FRONT DOOR LOCK ACTUATOR LEFT REAR DOOR LOCK ACTUATOR LIFTGATE LOCK ACTUATOR LOCK LT BLU WIRE LT GRN WIRE MIR/LCK FUSE 7 MIRRORS SYSTEM ORG/ WIRE PWR LKS FUSE 14 REMOTE CONTROL DOOR LOCK RECEIVER (BEHIND LOWER LEFT SIDE OF DASH) RIGHT DOOR LOCK AND WINDOW SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT REAR DOOR LOCK ACTUATOR SPLICE PACK TAN WIRE UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK TRC FUSE UNLOCK W/ KEYLESS ENTRY WHT WIRE
