Oldsmobile Bravada II (1995-2001) trip computer Wiring diagram

2.2L 4 DOOR AMPF FUSE 20 AMPLIFIER (PREMIUM SOUND) AUTOMATIC A/C AUX PWR FUSE 13 BLK WIRE BODY RELAY BLOCK CARGO LAMP (UTILITY) CIGAR LIGHTER CIGAR LTR FUSE 2 CTSY LP FUSE 8 DAYTIME RUNNING LAMP (DRL) RELAY (ENVOY) DRL FUSE HI BEAM FUSE DAYTIME RUNNING LAMP (DRL) RELAY (EX ENVOY) FOG LAMP RELAY DOME LAMP (UTILITY) DOME LAMP AND CENTER MOUNTED STOP LAMP (PICKUP) DOME LAMP (W/ SUNROOF) DOME LAMP (W/O SUNROOF) UNIVERSAL GARAGE DOOR OPENER DOOR UNLOCK RELAY DOOR LOCK RELAY DRIVER INFORMATION DISPLAY MODULE DRIVER'S DOOR UNLOCK RELAY ELECTRONIC CLIMATE CONTROL MODULE FLOOR CONSOLE AUXILIARY POWER OUTLET (ENVOY) FOG LP FUSE FROM ABS FUSE (DIAGRAM 2 OF 5) FUEL PUMP RELAY ECM B FUSE FULL TRIP (UTILITY) HDLP SW FUSE 7 HEADLAMP SWITCH I/P FUSE BLOCK INADVERTENT POWER LAMP RELAY INSTRUMENT CLUSTER INT BAT FUSE LEFT FRONT CONSOLE COURTESY LAMP LEFT HEADLAMP BALLAST (HID) LEFT POWER SEAT ADJUSTER SWITCH LOW BEAM RELAY (ENVOY) LT LOW FUSE MANUAL A/C NCA WIRE ORG/ WIRE POWER SEATS CIRCUIT BREAKER POWERTRAIN CONTROL MODULE (PCM) PWR LKS FUSE 14 RADIO RAP FUSE RDO BAT FUSE 19 REAR AUXILIARY POWER OUTLET (ENVOY) RED WIRE REMOTE AUDIO PLAYER (BRAVADA) RIGHT AUXILIARY POWER OUTLET LEFT AUXILIARY POWER OUTLET RIGHT FRONT CONSOLE COURTESY LAMP RIGHT HEADLAMP BALLAST (HID) RIGHT POWER SEAT ADJUSTER SWITCH RT LOW FUSE SEAT MEMORY MODULE LEFT POWER SEAT ADJUSTER SWITCH TAN WIRE TO HI BEAM FUSE (DIAGRAM 3 OF 5) TO HIGH BEAM RELAY (DIAGRAM 5 OF 5) TO PWR LCKS FUSE 14 (DIAGRAM 3 OF 5) TO RAP RELAY (DIAGRAM 5 OF 5) TO TBC FUSE (DIAGRAM 4 OF 5) TRANSFER CASE SHIFT CONTROL MODULE (W/ ELECTRIC TRIP COMPUTER UNDER- HOOD FUSE BLOCK UNDERHOOD FUSE BLOCK FROM INT BAT FUSE (DIAGRAM 3 OF 5) UTILITY VEHICLE CONTROL MODULE (VCM) VEHICLE INTERFACE UNIT (ENVOY) W/O FULL TRIP W/O MEMORY W/ MEMORY WHT WIRE YEL WIRE
