Oldsmobile Bravada II (1995-2001) to transfer case controls Wiring diagram
This page shows the only wiring diagram for the component.to transfer case controls, which is found in the car Oldsmobile Bravada II (1995-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram to transfer case controls (1 of 1)
AUTOMATIC TRANSMISSION CONTROLLER (IN CENTER FLOOR CONSOLE)
B/U LAMP FUSE 25
BLK WIRE
BODY RELAY BLOCK
BTSI SOLENOID
DK GRN WIRE
HOT IN RUN OR START
LT GRN WIRE
LT GRN/BLK WIRE
PARK SOLENOID
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
SPLICE PACK
TCC/STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
TO TRANSFER CASE CONTROLS
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK BTSI FUSE
WHT WIRE
Go to component -> Shift interlock circuit, with floor shift -> TO TRANSFER CASE CONTROLS
