Oldsmobile Bravada II (1995-2001) serial data line brake lamp control ebcm ground ppl Wiring diagram

ABS MAXI- FUSE ANTI-LOCK INDICATOR BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER DASH, ON HEATER CASE) BRAKE PRESSURE WARNING SWITCH (RIGHT END OF EBCM) BRAKE SW BRAKE WARNING INDICATOR BRN WIRE DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (LEFT FRONT INNER FENDER) FRONT AXLE SWITCH (ON FRONT AXLE) FUSE 15 GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN ABS FUSE 22 I/C LOGIC I/P FUSE BLOCK IGN INSTRUMENT CLUSTER LEFT FRONT WHEEL SPEED SENSOR RIGHT FRONT WHEEL SPEED SENSOR LFT FRT SENSOR (-) LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PARKING BRAKE WARNING LAMP POWERTRAIN CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) PPL PPL BRAKE SW INPUT PPL PPL PUMP MOTOR PUMP MOTOR HIGH PUMP MOTOR LOW PUMP MOTOR POWER GROUND RDO BATT FUSE 19 RED WIRE RT FRT SENSOR (-) LFT FRT SENSOR (+) RT FRT SENSOR (+) SERIAL DATA LINE BRAKE LAMP CONTROL EBCM GROUND PPL SPLICE PACK STOP LAMP SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) TAN WIRE TO TRANSFER CASE CONTROL TRANSFER CASE CONTROL MODULE UNDERHOOD FUSE BLOCK VEHICLE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) VOLTAGE REG VSS VSS INPUT WHT WIRE YEL WIRE YEL/BLK WIRE
