Oldsmobile Bravada II (1995-2001) rear wiper/washer switch and endgate/ lifgate window release switch Wiring diagram
This page shows the only wiring diagram for the component.rear wiper/washer switch and endgate/ lifgate window release switch, which is found in the car Oldsmobile Bravada II (1995-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear wiper/washer switch and endgate/ lifgate window release switch (1 of 1)
BLK WIRE
DK GRN WIRE
GRY WIRE
HI LO
HOT AT ALL TIMES RR W/W FUSE
HOT IN ACCY OR RUN
I/P FUSE BLOCK (LEFT END OF DASH)
OFF
ORG/ WIRE
PUMP (IN WASHER RESERVOIR)
REAR WINDOW WASHER
REAR WINDOW WIPER CUTOUT SWITCH AND LIFTGATE AJAR JAMB SWITCH
REAR WINDOW WIPER MOTOR (TOP CENTER OF REAR ENDGATE) LOGIC
REAR WIPER/WASHER SWITCH AND ENDGATE/ LIFGATE WINDOW RELEASE SWITCH
RR WPR FUSE 23
UNDERHOOD FUSE BLOCK (TOP OF LEFT FRONT FENDER)
WASHER SWITCH
WHT WIRE
WIPER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> REAR WIPER/WASHER SWITCH AND ENDGATE/ LIFGATE WINDOW RELEASE SWITCH
