Oldsmobile Bravada II (1995-2001) rear dn recl fwd Wiring diagram
This page shows the only wiring diagram for the component.rear dn recl fwd, which is found in the car Oldsmobile Bravada II (1995-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear dn recl fwd (1 of 1)
BLK WIRE
BLU WIRE
BODY RELAY BLOCK
DK DK
DK LT
FRT DN REAR UP
FRT UP BACK
GRN WIRE
HOT AT ALL TIMES PWR SEATS CIRCUIT BREAKER
LEFT SEAT ADJUSTER SWITCH
LT DK
LT LT
LT LT LT
ORG/ WIRE
REAR DN RECL FWD
REAR DN RECL FWD RECL RWD
REAR UP FRT DN
RECL RWD
RIGHT SEAT ADJUSTER SWITCH
SEAT FRONT HEIGHT MOTOR
SEAT LATERAL MOTOR
SEAT RECLINER MOTOR SEAT REAR HEIGHT MOTOR
TAN WIRE
YEL WIRE
Go to component -> 6-way & recliner power seat circuit -> REAR DN RECL FWD
