Oldsmobile Bravada II (1995-2001) radio, electronic climate control module pnk Wiring diagram

1-2 SHIFT SOL 10 13 29 30 422 687 TCC SOL CTRL 3-2 SOL CTRL VSS LO VSS HI 2-3 SHIFT SOL 3-2 SHIFT SOL A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH ABS FUSE 22 ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES SYSTEM CRUISE CONTROL SYSTEM PPL PPL AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BLU DK WIRE BRN WIRE BRN/WHT WIRE CLSTR FUSE 11 DK BLU WIRE DK GRN WIRE ECM I FUSE ECM-B FUSE ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN HOT IN RUN OR START HOT IN RUN, OFF OR START I/P FUSE BLOCK (LEFT SIDE OF DASH, I/P FUSE BLOCK RDO BATT FUSE 15 IGNITION CONTROL MODULE INSTRUMENT CLUSTER JUNCTION CONNECTOR LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT PPL MALFUNCTION INDICATOR LAMP NCA WIRE ORG/ WIRE PNK PNK WIRE PNK WIRE PPL PPL DATA LINK CONNECTOR (PARTIAL) PPL/WHT WIRE PRESSURE CONTROL SOLENOID RADIO, ELECTRONIC CLIMATE CONTROL MODULE PNK WIRE RED WIRE RED/BLK WIRE REV RUN WIRE SOLID STATE SPLICE PACK STOP LAMP SWITCH TAN WIRE TAN/BLK WIRE TCC PWM SOL TCC SOL THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANSMISSION FLUID TEMPERATURE SENSOR TWISTED WIRE PAIR UNDERHOOD FUSE BLOCK VEHICLE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) VEHICLE SPEED SENSOR W/ AUTO A/C WHT WIRE YEL WIRE YEL/BLK WIRE
