Oldsmobile Bravada II (1995-2001) park lps in key in ign Wiring diagram
This page shows the only wiring diagram for the component.park lps in key in ign, which is found in the car Oldsmobile Bravada II (1995-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park lps in key in ign (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BEHIND DASH, ON HEATER CASE)
BRN WIRE
CRUISE FUSE 3
DK BLU WIRE
DK BLU/WHT WIRE
DOOR JAM SWITCH HEADLAMP REQ
FRONT LT LEFT FUSE 14
FRONT RT TURN FUSE 13
GAUGES FUSE 4
GROUND BATTERY GROUND
HEADLAMP SWITCH
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK TBC FUSE
HOT IN PARK OR HEAD
HOT IN RUN AND START
I/P FUSE BLOCK
IGNITION 3 SEAT BELT INPUT
IGNITION KEY ALARM SWITCH
LEFT DOOR JAMB SWITCH
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
ORG/ WIRE
PARK LPS FUSE 5
PARK LPS IN KEY IN IGN
PKLP AUTO HDLP
PNK IGNITION ON INPUT LEFT TURN SIG RIGHT TURN SIG WIRE
PNK WIRE
POWER DISTRIBUTION CENTER
PPL
PPL/WHT WIRE
RIGHT FRONT PARK AND TURN SIGNAL LAMP LEFT FRONT PARK AND TURN SIGNAL LAMP
SEAT BELT SWITCH (UNDER LEFT FRONT SEAT)
TAN WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
Go to component -> Warning system circuits -> PARK LPS IN KEY IN IGN
