Oldsmobile Bravada II (1995-2001) ignition switch accy Wiring diagram
This page shows the only wiring diagram for the component.ignition switch accy, which is found in the car Oldsmobile Bravada II (1995-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition switch accy (1 of 1)
4.3L 2.2L
A/T M/T
B STUD
BATTERY
BATTERY MAXIFUSE
BLK WIRE
BULB TEST
FUSE HOLDER (RIGHT OF RADIATOR)
FUSIBLE LINK (10 GA-
GENERATOR
HOLD- IN COIL PULL- IN COIL
HOT AT ALL TIMES
IGN A FUSE
IGNITION SWITCH ACCY
LOCK
M/T A/T
OFF
ORG/ WIRE
P/N
PPL
PPL A/T M/T
PPL PPL
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY
STARTER SOLENOID
UNDERHOOD FUSE BLOCK (LEFT FRONT FENDER)
UNDERHOOD FUSE BLOCK (LEFT FRONT FENDER) CRANK FUSE
UNDERHOOD FUSE BLOCK (LEFT FRONT FENDER) IGN C FUSE
WHT WIRE
YEL WIRE
Go to component -> Starting circuit -> IGNITION SWITCH ACCY
