Oldsmobile Bravada II (1995-2001) endgate or liftgate window release actuator Wiring diagram
This page shows the only wiring diagram for the component.endgate or liftgate window release actuator, which is found in the car Oldsmobile Bravada II (1995-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram endgate or liftgate window release actuator (1 of 1)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (UNDER DASH, ON HEATER CASE)
BODY RELAY BLOCK (LEFT SIDE OF DASH)
ENDGATE OR LIFTGATE LOCK CYLINDER SWITCH
ENDGATE OR LIFTGATE WINDOW RELEASE ACTUATOR
HOT AT ALL TIMES
LEFT FRONT DOOR LOCK ACTUATOR (OPEN W/ DOOR LOCKED)
LIFTGLASS RELAY
LIFTGLASS SW
LT BLU WIRE
MIR/LCK FUSE
ORG/ WIRE
PARK BRAKE SWITCH
PARK BRAKE WARNING SWITCH
REAR WINDOW WIPER/WASHER SWITCH AND ENDGATE/LIFTGATE WINDOW RELEASE SWITCH
RELAY CNTRL
UNDERHOOD FUSE BLOCK
WHT/BLK WIRE
Go to component -> Rear glass release circuit -> ENDGATE OR LIFTGATE WINDOW RELEASE ACTUATOR
