Oldsmobile Bravada II (1995-2001) 7 8 9 10 11 12 fused ign ground vss in air temp int lite dim parklamps Wiring diagram

43 1127 FUSED BATT SERIAL DATA 7 8 9 10 11 12 FUSED IGN GROUND VSS IN AIR TEMP INT LITE DIM PARKLAMPS AIR BAG AMBIENT AIR TEMPERATURE SENSOR (FRONT CENTER OF VEHICLE, NEAR HOOD LATCH) ANTI-LOCK IND BATTERY FUEL BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (UNDER DASH, ON HEATER CASE) BODY RELAY BLOCK (BEHIND LEFT SIDE OD DASH, NEAR I/P FUSE BLOCK) BODY RELAY BLOCK (BEHIND LEFT SIDE OF DASH, NEAR I/P FUSE BLOCK) BRAKE IND BRN WIRE BRN/WHT WIRE CHECK GAUGES IND CLR IC LOGIC CLSTR FUSE 11 COMPASS REMOTE SENSOR (IN HEADLINER ABOVE LEFT FRONT SEAT) CRUISE FUSE 3 CTSY LAMP FUSE 8 DK BLU/WHT WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE COOLANT TEMPERATURE GAUGE EXTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM FUEL GAUGE GAUGES FUSE 4 GRN WIRE GRY WIRE HIGH BEAM IND HOT AT ALL TIMES HOT IN ACCY, RUN OR RAP HOT IN OFF, RUN OR START HOT IN RUN HOT IN RUN OR START HOT W/ INT DIMMING ON I/P FUSE BLOCK (LEFT END OF DASH) ILLUM FUSE 12 IGN 1 ILLUMINATION INSTRUMENT CLUSTER LEFT TURN LOW FUEL LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MIL (SERVICE ENGINE SOON IND) OIL PRESSURE GAUGE ORG/ WIRE ORG/BLK WIRE OVER SPEED ALARM IND OVERHEAD CONSOLE (UTILITY ONLY) PARK POSITION SWITCH (PART OF AUTOMATIC TRANSMISSION CONTROLLER) PNK PNK WIRE PNK WIRE PNK/BLK WIRE PPL/WHT WIRE PRNDL RDO BATT FUSE 19 RDO FUSE 24 RED WIRE RIGHT TURN SEAT BELT IND SECURITY IND SERVICE SERVICE BODY SYSTEM IND SPARE SPEEDOMETER SPLICE SPLICE PACK TACHOMETER TAIL GATE ALARM IND TAN/WHT WIRE TRANSFER CASE SHIFT CONTROL MODULE (BEHIND RIGHT FRONT KICK PANEL) TRIP/ ODO UNDERHOOD FUSE BLOCK (ON TOP OF LEFT FRONT FENDER) UPSHIFT IND VOLT REG VOLT- METER W/ TRIP COMPUTER WHT WIRE YEL WIRE
