Trunk & fuel door release circuit for Oldsmobile Aurora II (1999-2003)
Trunk & fuel door release circuit
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DDDM)
DRIVER DOOR SWITCH ASSEMBLY (DDSA)
F/TNKDR REL RELAY
FUEL DOOR RELEASE ACTUATOR (BEHIND FUEL FILTER DOOR)
FUEL DOOR RLY CTRL TRUNK REL RLY CTRL CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA
GARAGE DOOR OPENER
HOT AT ALL TIMES ALDL FUSE
HOT AT ALL TIMES BODY FUSE
LT BLU WIRE
ORG/ WIRE
PNK WIRE
PNK/WHT WIRE
PPL PPL 1807 1807
PPL PPL 1807 1807 CLASS 2 SERIAL DATA CLASS 2 SERIAL DATA PWR DOOR SERIAL DATA
REAR COMPARTMENT LID RELEASE ACTUATOR (AT REAR OF REAR COMPT LID)
REAR INTEGRATION MODULE (NEAR UPPER LEFT CORNER OF REAR SHELF PANEL)
RED WIRE
RED/BLK WIRE
TAN/WHT WIRE
TRK REL RELAY
TRUNK AJAR SW
TRUNK AJAR SW SIG
TRUNK REL SW FUEL DOOR REL SW
VALET SWITCH
WHT WIRE
